DESCRIPTION

Basic Info.

Model NO.	L6
Activity	Passive
Operation Mode	Wire / Remote Control
Speaker System	Optional Combination
Speaker Material	Wood
Application	Commercial, Home
Certification	CE, RoHS, FCC
Monitor	VFD Screen
THD	<0.005%
L-6	1X15 Inch; 1X10 Inch, 1X3 Inch Tri-Amped
Hron	Fully Horn Loaded Compact Enclosure
Transport Package	Double Durable Cartons or Flight Cases
Specification	Single 15 Speaker
Trademark	Sanway Audio
Origin	Made in China
HS Code	8518500000
Production Capacity	2000 PCS Per Month

Product Description

EVO6E Single 15 Inch 3 Way Neodymium Drivers Wooden Cabinet Full Range Sound Speaker System for DJ Nightclub

1x15 inch; 1x10 inch, 1x3 inch tri-amped
High performance neodymium speaker drivers
Fully horn loaded compact enclosure
Fitted with M10 fly points

Overview:

L-6 is dj sound speaker system equipped with horn loaded 15" neodymium low frequency drivers, a 10" neodymium mid frequency driver, a 1.4"exit high frequency neodymium driver, offering high-intensity sound. L-6 3 way speaker is perfect for DJ monitoring, outdoor live band performance, installation of nightclub, ect.

Features:

3 way, tri-amped with high efficient performance

Fully horn loaded compact enclosure

High performance neodymium speaker drivers

Fitted with M10 fly points

Specification:

Model	L-6
Frequency Response( ±3dB)	55Hz-18KHz
Sensitivity(1w/1m)	LF:103dB
	MF:108dB
	HF:109dB
Crossover Point	250Hz
Nominal Impedance	LF:8ohms
	MF:16ohms
	HF:32ohms
Power rated (AES)	LF:400 watts
	MF:250 watts
	HF:75 watts
Operating Band	LF: 50/80 - 200Hz
	MF:500 - 4kHz
	LF:4kHz - up
Nominal dispersion	50 ° ×25 °V
Enclosure material	18mm plywood
Surface finished	Black or Violet color selectable
Net weight	57kg passive/ 63kg powered
Low frequency driver	1 ×15 inch
Mid frequency driver	1 x 10 inch
High frequency driver	1 ×3 inch
Input Connectors	2 x Speakon NL8

Dimension:
